Description
Tempered glass frameless shower door HG-F01
Glass thickness: 8/10mm
Glass : unltra clear/ Float Tempered glass
Standard color: mirror light / rose gold / flange gold / matte black / gold
Customized Size:
W: 800-1300
L: 800-1500
H: 1850-2200
Why choose us:
1. Can accept small quantity order
2. Accept customized
3. Handle optional
4. Towel rack optional (with/without)
5. Glass self-cleaning (more selling points)
6. Contains installation hardware (convenient installation and more thoughtful)
7, with installation instructions (conform European and American habits)
8. Square tube/round tube/stainless steel/wire drawing and gloss (more abundant products)
9. Carton packaging (Both project and supermarket)
1. Production process
Cutting-edging-rounded corners-water jet-punching-silk screen-tempering-self-cleaning liquid / safety explosion-proof film-packaging
Cut Two edges grinding
Round Corner Machine hole puncher
curve tempered glass Bathroom door
Glass film
Nano self-cleaning liquid
2. Quality Control
2.1 Each glass must be inspected to confirm before entering the factory;
2.2 Quality control in the production process are in accordance with quality control standards.
First inspection-self-inspection-special inspection-factory inspection, product standards are strictly implemented in accordance with customer technical documents or industry standards;
2.3 The dimensional accuracy and tempering quality inspection data of processed products shall be recorded and archived with traceability;
2.4 The bending degree of toughened grain is tested, the bending degree is 1.5‰, and the grain size is 55-80 grains per 50*50mm
3. The company's certification qualifications
The company's products have passed European CE certification and American SGCC certification
4. 10years of export packaging experience: Carton foam packaging and fumigation-free wooden box packaging can be realized to ensure product transportation safety;
5. The company's equipment processing capacity
Focus on the manufacture of tempered glass for home appliances for 14 years. The company has comprehensive equipment capabilities for processing high-temperature silk screens, including Italian Bottero cutting machines, Bottero edging machines, CNC machining centers, automatic punching machines, automatic rounding machines, automatic screen printing machines, tempering furnaces and other equipment.
-Choose Taiwan Glass or Jinjing Automotive Grade Original Float glass
-Polished straight edges, size tolerance ±1mm, uniform edge 1mm
-Safety corner or round corner treatment
-Water jet cutting, accurate size, vertical water jet with safety angle,
-Even tempered grain
-Fumigation-free wooden box packaging, firm and safe
-Can provide carton foam sales packaging
-Self-cleaning nano coating can be applied
-Safety explosion-proof film can be attached
Glass processing range:
Thickness: 3mm, 3.2mm, 4mm, 5mm, 6mm, 8mm, 10mm, 12mm
Glass color: chear glass, ultra clear glass, tinted glass,reflective glass
Edging: straight edge, round edge
Tempering: C shape and J shape
Silk screen: high temperature screen printing, frosted screen printing
shower room: shower room assembly
Other processes: can be coated with nano self-cleaning liquid (from Germany, 10-year warranty),
Safety explosion-proof film can be attached
Packing: plywood wooden box and carton + foam separate sales packaging
As China is in line with international standards and the domestic technology level has gradually matured, frameless shower enclosure is not difficult for most manufacturers, and barriers to entry into the industry have become lower and lower. Since 2003, there have been dozens of formal shower room manufacturers nationwide. At the same time, the original workers of some shower room manufacturers began to break away from the enterprises to start their own businesses, and the purchase channels were varied, with mixed good and bad, which had a significant impact on the overall shower room market. With the improvement of people's living standards, people pay more and more attention to the safety, beauty, and good reputation of shower room products. The time has entered in 2009. After the survival of the fittest in the entire market of the shower room, the big waves wash away the sand, many excellent showers Housing brands stand out.
Acrylic sheet: mainly depends on the glossiness of the acrylic sheet and the thickness of the back treatment. Under direct light, a good acrylic sheet has a good light-proof effect, uniform light transmission, and feels by hand. A good material has a thick texture and is not easy to deform. The quality of pulleys and hinges directly affects the normal use of the product. Good pulleys and hinges have smooth sliding and switching, low noise, and copper material. Large manufacturers of brands generally have their own patented pulleys and hinges.
Safety: Related to glass material, it can be divided into ordinary glass, tempered glass and acrylic. Ordinary glass is cheap and unsafe to use. Tempered glass is often used. At least 5MM tempered glass is used. It has strong impact resistance and is not easy to break. . The glass with strong safety generally has a toughened identification mark CCC. Acrylic is also called plexiglass. The windshield in front of the aircraft is also made of this material, so there is no risk of self-destruction.
Waterproof: It is popular to separate wet and dry, considering the tightness of the seam. Sealing tape must be used to prevent water seepage.
